Description
Digital Chronometer, 2.25″ Front Mount, FAA-PMA Approved
- Greenwich Mean Time
- Local Time
- Flight Time Recorder
- Elapsed Time Counter
- Bright sunlight-readable, incandescent displays.
- Illuminated buttons and annunciators for night operations. Automatic display dimming.
- Patent-pending, two-button control that is natural and error free, no accidental time setting.
- Quartz crystal precision time reference.
- Elapsed time count down timer with alarm.
- Flight time recorded in hours, minutes or tenths of hours.
FAA Approved Model List.
If your airframe is not shown on the list, it is recommended a FAA form 337 should be filed with the local FSDO.
- Mystere Falcon 50 and 900
- Learjet Airplanes 35A and 50
- Bae Jetstream Model 4101
Related products
2″ Lighted Digital Electric Horizon Gyro, 9-32 volt, TSO
$2,332.00
ELECTRICAL REQUIREMENTS
- Operating voltage: 9 to 32VDC
- Current draw: 0.20 A Max
- Circuit breaker: 2 amps
- Length: 1.22 in. max.
- Width: 3.37 in. max
- Height: 3.37 in. max
- Weight: 6.75 oz
- Length: 1.22 in. max.
- Width: 2.75 in. max
- Height: 2.4 in. max
- Weight: 4.75 oz
- MATING CONNECTOR: (MS3116E8-4S) & screws included
- CERTIFICATIONS: TSO-C4c, TSO-C113a, DO-160G, and DO178B Level C
- EASA SPECIFICATION CONFORMANCE: ETSO-C4c and ETSOC-113
3″ RCA1510 Digital Heading Indicator, 9-32 volt, TSO
$2,332.00
- OPERATING VOLTAGE: 9 to 32VDC
- RUNNING CURRENT: (14VDC system) 0.20 AMPs MAX; (28VDC system) 0.15 AMPs MAX
- CIRCUIT BREAKER SIZE: 1 AMP
- ACCURACY: 2 DEGREES
- OPERATING TEMPERATURE RANGE: -20º TO +55º C
- MATING CONNECTOR: MS3116E8-4S OR EQUIVALENT
- WEIGHT: 8.35 oz. Max
- FAA SPECIFICATION CONFORMANCE: TSO-C6e, TSO-C113a, DO-160G & DO-178B Level C
AV-30-C EFIS Display, FAA-PMA
$2,156.00
- Input Power Nominal: 6 Watts (0.5 Amps @ 12VDC)
- Input Power Max: 12 Watts (1.0 Amps @ 12VDC)
- Required Circuit Breaker: 2 Amp
- Operation on Battery: 2 Hours Typ @ 20°C / 30 Minutes Min @ -20C
- Physical Attributes
- Mounting Configuration: 3 1/8” Round Instrument Hole
- Dimensions wo/Connector: 3.38 x 3.38 x 1.6 Inches
- Weight: 0.50 Lbs.
- Electrical Connector: 15 Pin Male D-Sub
- Pneumatic Connectors: ¼" OD Quick Connect
- Mounting: (4X) #6-32 Machine Screws
- Case Material: Billet Aluminum
- Environmental
- Operating Temp: -20°C to +55°C
- Storage Temp (48 Hrs): -30°C to +80°C
- Humidity (48 Hrs): 90% RH
- Display
- Diagonal Size: 3” Circular
- Contrast Ratio (Typical): 500
- Brightness (Typical): 1000 cd/m2
- Viewing Angle Left/Right: 60°
- Viewing Angle Up: 45°
- Viewing Angle Down: 10°
- Backlight Lifetime (Typical): 50,000 Hrs
Unlit Electric Horizon Gyro 14 volt, TSO
$1,874.00
