MicroBurst LED Nav Taillight, with CometFlash Strobe
$268.00
Description
Whelen MicroBurst LED Nav Taillight, with CometFlash 180° Strobe, for Experimental/LSA aircraft
- Includes both Red and Green lights in kit
- 14 VDC.
- Low current, long life, lightweight.
- Self-contained (no external power supply needed).
- Aerodynamic with vibration and moisture resistance.
- Synchronizable.
- Replaceable lenses.
- Super bright, rivaling strobe in impact.
- Available with CometFlash, the lighting concept that revolutionized aviation lighting.
Look to Whelen Engineering, with more than fifty years experience in aviation lighting and the acknowledged pioneers in the development of LED technology, for stateof-the-art lighting for your experimental or LSA aircraft. LEDs are lightweight, low current and incredibly bright, vibration and moisture resistant… the ideal lighting technology for your needs.
Related products
71080 Series Red LED Beacon
$649.00
MAXDIM Single Light Intensity Control Unit, with Spade Terminals, by Seaton
$273.00
- Weight: 0.58 oz (16.6 g)
- Dimensions: 1.25" diameter
- Voltage Range: 12 to 35VDC
- Max Current: 12.5 A
- Controlled Output: 0 to 12-35 VDC 0 to 12.5 A
- Capacity:
- 150 watts @ 12 VDC
- 288 watts @ 24 VDC
- 350 watts @ 28 VDC
- 440 watts @ 35 VDC
- Install with standard supplied solderless crimp connectors
- Potentiometer rotation: 270?
- Rotational life: 500K turns
- Operating temperature range: -30° C to +65° C
- Internal temperature protect: +85°C
- Storage temperature: -40° C to +100° C
- Maximum internal temperature: @12.5A +15° C
- Enclosure material: Bayer FR 110 Resin meets UL 94
- Flame rating: V-2 (0.03in) V-0 (0.059in) 5VB (0.098in) 5VA (0.13in)
- RTCA/DO-160E Qualified
- FAA PMA STC SA01800SE
MAXPULSE Landing Light Controller, with #6 ring terminals, by Seaton
$300.00
- Weight: 1 oz
- Diameter: 1.25"
- Voltage range: 12 to 35VDC, up to 700 watts total
- Max current: 10 A per circuit
- Circuits: 2
- Capacity per circuit:
- 120 watts @ 12 VDC
- 240 watts @ 24 VDC
- 280 watts @ 28 VDC
- 350 watts @ 35 VCD
- Installed with standard supplied solderless crimp ring lug terminals
- Operating temperature range: -30° C to +65° C
- Internal temperature protect: +85° C
- Storage temperature: -40° C to +100° C
- Maximum internal temperature: @ 10 A +25° C above ambient
- Enclosure material: Bayer FR110 resin meets UL 94
- Flame rating: V-2 (0.03in) V-0 (0.059in) 5VB (0.098in) 5VA (0.13in)
- Full STC/PMA
- RTCA/DO-160E Qualified
MAXPULSE Landing Light Controller, with spade connectors, by Seaton
$300.00
- Weight: 1 oz
- Diameter: 1.25"
- Voltage range: 12 to 35VDC, up to 700 watts total
- Max current: 10 A per circuit
- Circuits: 2
- Capacity per circuit:
- 120 watts @ 12 VDC
- 240 watts @ 24 VDC
- 280 watts @ 28 VDC
- 350 watts @ 35 VCD
- Installed with standard supplied solderless crimp ring lug terminals
- Operating temperature range: -30° C to +65° C
- Internal temperature protect: +85° C
- Storage temperature: -40° C to +100° C
- Maximum internal temperature: @ 10 A +25° C above ambient
- Enclosure material: Bayer FR110 resin meets UL 94
- Flame rating: V-2 (0.03in) V-0 (0.059in) 5VB (0.098in) 5VA (0.13in)
- Full STC/PMA
- RTCA/DO-160E Qualified
